规格 mm |
长 |
500 |
1000 |
1500 |
2000 |
2500 |
3000 |
3500 |
4000 |
5000 |
5000 |
6000 |
6000 |
|
高 |
60 |
60 |
60 |
100 |
100 |
100 |
100 |
150 |
150 |
175 |
150 |
175 |
|
|
工作面宽 |
30 |
30 |
30 |
40 |
40 |
40 |
40 |
80 |
80 |
80 |
80 |
80 |
|
|
筋厚 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
10 |
10 |
10 |
10 |
10 |
|
|
圆角 |
4 |
4 |
4 |
6 |
6 |
6 |
6 |
8 |
8 |
10 |
8 |
10 |
|
|
精度等级 |
0 |
0 |
1 |
1 |
2 |
2 |
2 |
2 |
3 |
2 |
3 |
2 |
|
|
直线度(mm) |
0.003 |
0.005 |
0.015 |
0.018 |
0.056 |
0.056 |
0.064 |
0.064 |
0.16 |
0.08 |
0.20 |
0.10 |
|
|
平行度(mm) |
0.004 |
0.008 |
0.022 |
0.027 |
0.084 |
0.084 |
0.13 |
0.13 |
0.24 |
0.12 |
0.30 |
0.15 |
|
|
重量(kg) |
0.8 |
1.5 |
2.3 |
6 |
10 |
10 |
28 |
28 |
35 |
40 |
42 |
50 |
|
